- BCM 350, wall fixing. Dual flush outlet valve, factory preset 6/4 litres flush, NF approved. Water saving and quiet fill delayed action inlet valve NF approved. Conforms to EN 14055 Class 2 flushing standards, BREEAM requirements and UK Building Regulations.
- Front flush plate operation. Supplied with bright chrome Ying Yang dual flush plate, NF approved, WC connector and drainage set.
- White wall hung ceramic WC. Conforms to NF, EN 997 Class 2 flushing standards, BREEAM requirements and UK Building Regulations
- White thermoplastic Opio Classic toilet seat, with stainless steel hinges, NF approved.
WC PACK STANDARD SAMOA
Réf: 31 1858 15
Complete pack comprising BCM 350 wall frame, 6 litre insulated cistern with NF approved components. Factory preset at 6/4 litres with integral dual flush outlet valve and a water saving and quiet fill delayed action inlet valve. Water inlet connection onthe inside of the cistern fitted with an integral isolating valve. Front flush plate operation.
Supplied with fixing accessories for floor or wall fixing, dual flush plate, accessories for protection during the construction phase, ceramic wall hung WC, white thermoplastic toilet seat with stainless steel hinges, 90° outlet pipe and WC connectors.
| Ref. | Barecode | Packing | Packing | Pallet Quantity |
|||
|---|---|---|---|---|---|---|---|
| Nb | M² | Kg | |||||
| WC pack STANDARD SAMOA | 31 1858 15 | 3 24723 004059 9 | Carton | 1 | 0,131 | 38,00 | 15 |
